Caldwell Sleeve Lifter MCL-1/2, two leg

Single-operator casting lift. 1,000 lb capacity.

The two-leg Caldwell manhole sleeve lifter. Its steel legs give it a slim profile, though it requires more storage space than the three-leg version. Both models are in regular service with our customers.

$899.00

Lead time is approximately one week.

Ships at no charge. Shipping is included on the Caldwell sleeve lifters.

To place an order with a Purchase Order, call (952) 949-2430 or email sales@grapplerusa.com.

Ordering more than 10? It ships at our standard rates, or call us if you would rather we quote the freight.

Dimensions

Dimensioned drawing of the two-leg MCL-1/2: legs at 60 degrees, 36.6 in overall, and a flange range of 12 to 30 in diameter — Caldwell’s dimensions for the two-leg frame, including the 12 in to 30 in flange range

Features

1,000 lb lifting capacity
Two steel legs, slim profile
Unit weight 24 lb
Fits flange diameters from 12 in to 30 in
Shipped at no charge
Lead time of approximately one week

Check the sleeve before ordering either model. Both are friction grip lifters for flanges of 12 in to 30 in diameter, and neither is for straight walled lifts. The MCL-3/4 is the same tool with three legs and 1,500 lb capacity. Replaces the discontinued Grappler Casting Puller.

See it working

Questions before ordering?

Please call to speak with someone familiar with the product. Inquiries regarding dealer pricing, volume orders, and municipal specifications are welcome.

(952) 949-2430 Send a message

Truck crew kit

Choose this when: The crew works off a truck, and the heaviest section on the job is what sizes the tools.

1 × Manhole Pick "Mary A", 12 lb $270.00
1 × Caldwell Sleeve Lifter MCL-3/4, three leg $1,594.00
1 × Manhole Debris Catcher $725.00
1 × 25 ft Rope & Hook $105.00

$2,694.00

Walking crew kit

Choose this when: The crew moves between structures on foot all day, and everything has to be carried.

1 × Manhole Pick "Jake", 8 lb $255.00
1 × Manhole Debris Catcher $725.00
1 × 25 ft Rope & Hook $105.00

$1,085.00

Caldwell Sleeve Lifter MCL-1/2, two leg $899.00
